Waterproof Speaker Cable

Application:High-End Audio Transmission, Stereo, Professional Sound & Studio Requirements, High Resolution Monitoring, Speaker Level Analog Audio, Permanent Installation, Broadband and Baseband Analog Video Physical Characteristics:Conductor：Oxygen-free Stranded Bare Copper as below tableInsulation Material: FR-Retardant PVCWrap：Water-block TapeJacket Material: FR-Retardant PVC or PEData table:No. Of CoresConductor Size (AWG)StrandingInsulation DiameterInsulation Color CodeJacket Color CodeOverall Diameter21665*0.16mm2.10mmRed-BlackBlack7.60mm Electrical an...

Contáctanos

Consulta en línea

E-mail：pony@hiliion.com

Whatsapp：+86 137 5084 5392

Introducción detallada

Application:

High-End Audio Transmission, Stereo, Professional Sound & Studio Requirements, High Resolution Monitoring, Speaker Level Analog Audio, Permanent Installation, Broadband and Baseband Analog Video

Physical Characteristics:
Conductor：Oxygen-free Stranded Bare Copper as below table
Insulation Material: FR-Retardant PVC

Wrap：Water-block Tape

Jacket Material: FR-Retardant PVC or PE

Data table:

No. Of Cores	Conductor Size (AWG)	Stranding	Insulation Diameter	Insulation Color Code	Jacket Color Code	Overall Diameter
2	16	65*0.16mm	2.10mm	Red-Black	Black	7.60mm

Electrical and Environmental Properties：

Operating Voltage: 300 Volts Max
Installation: 0 to +60 ℃
Storage & Operation: -20 to + 75 ℃

Legend (Surface Ink Print):
4002107 c(ETL)us AUDIO CABLE 16AWG 2 COND 65 STRANDED OXYGEN FREE OUTDOOR UV DIRECTO BURIAL RoHS ZONE/A B C D E 0 1 2 3 4 5 6 7 8 9 002FT......500FT

Packing:

Option A): 1000ft/wooden reel

Option B): 500ft pull box

Certifications & Approval:

ISO9001, ISO14001, OHSAS18001
UL444，UL13

RoHS:Compliant Directive 2011/65/EU
